Connecting the RS-422 Connector Panel
PDR100 Installation
3-13
Connecting the RS-422 Connector Panel
The RS-422 Interface is located in slot 17. This is an EISA-only slot. The rear-panel
connector is the receptacle for the cable from the RS-422 Connector Panel, which
provides eight addressable RS-422 ports. See Figure 3-14.
Figure 3-14. Cable Connection Between the PDR100 and RS-422 Connector Panel
9040-10
RS-422 Communications (Ports 1-8)
