Maintenance
Drive Belt Tension Data
Specifications are listed below for deflection and sonic tension. Sonic tension measurement
requires Gates Sonic Tension Meter 507C or an equivalent.
Drive Belt Deflection (Using PV-43532 Tension Gauge)
Drive Belt Sonic Tension (Using Sonic Tension Meter)
Deflection
VISION 8-BALL All other VISION
15 mm ± 0.5 mm 32 mm ± 0.5 mm
Required Data
Sonic Tension
VISION 8-BALL All other VISION
Span 708.6
26 Hz ± 1 20 Hz ± 1
Belt Width 28 mm
Belt Mass Constant 8.4
