Maintenance
Mechanical Clutch Lever Lubrication
1. Remove the right side access cover. Loosen the clutch
cable adjuster lock nut.
2. Turn the cable adjuster completely inward to provide
maximum lever freeplay.
3. Remove the clutch lever pivot nut and screw. Disconnect
the clutch cable from the clutch lever.
4. Remove any old grease and dirt from the lever and
housing. Lubricate the clutch lever and pivot screw with
VICTORY Moly Assembly Grease or VICTORY All
Purpose Grease.
5. Reconnect the clutch cable. Reinstall the lever, pivot
screw and nut. Hold the screw down and tighten the nut.
Torque: 40 in-lbs (5 Nm)
6. Adjust clutch lever freeplay. See page 178.
AP
Pivot
Nut
Pivot Screw
