Maintenance
Headlamp Aim Adjustment
The high beam should shine straight forward. The low beam will spread more toward the
right (U.S./Canada).
1. Verify that tire pressure is at specification. See
page 191. Verify that rear suspension ride height
(preload) is at specification. See page 160.
2. Position the motorcycle on a level surface with
the headlight approximately 25 ft. (7.6 m) from
a wall. Measure the distance from the floor to
the center of the headlight and make a mark on
the wall at the same height.
3. Sit in the operator's seat. Bring the motorcycle
to the fully upright position.
4. Move the ignition switch to the ON position and
switch the headlamp to high beam. Observe the headlight aim on the wall. The top of the
beam should be slightly below the mark on the wall.
25 ft. (7.6 m)
Center Mark
X
