17 HEIDENHAIN TNC 410, TNC 426, TNC 430
2.2 Moving the Machine Axes
Traversing with the machine axis direction buttons is a
machine-dependent function. Refer to your machine tool
manual.
To traverse with the machine axis direction buttons:
Select the Manual Operation mode.
<
Press the machine axis direction button and
hold it as long as you wish the axis to move.
...or move the axis continuously:
and Press and hold the machine axis direction
button, then press the machine START button:
The axis continues to move after you release
the keys.
To stop the axis, press the machine STOP
button.
You can move several axes at a time with these two methods.
You can change the feed rate at which the axes are traversed with
the F soft key (see section 2.3 ”Spindle Speed S, Feed Rate F and
Miscellaneous Functions M”). This function is not available on
TNC 410.
