HEIDENHAIN TNC 410, TNC 426, TNC 430 347
14.1 Gener
al User P
ar
amet
ers
Graphic display mode
MP7310
Projection in three planes according to ISO 6433, projection
method 1: +0
Projection in three planes according to ISO 6433, projection
method 2: +1
Do not rotate coordinate system for graphic display: +0
Rotate coordinate system for graphic display by 90°: +2Display new
BLK FORM in Cycle G53/G54 DATUM SHIFT referenced to the
previous datum +0
Display new blank form in Cycle G53/G54 DATUM SHIFT referenced to
the new datum: +4 (not TNC 410)
Do not show cursor position during projection in three planes: +0
(not TNC 410)
Show cursor position during projection in three planes: +8
(not TNC 410)
Settings for the programming graphics (not TNC 426, TNC 430)
MP7311
Do not show penetration points as circle: +0
Show penetration points as circle: +1
Do not show meander paths in cycles: +0
Show meander paths in cycles: +2
Do not show compensated paths: +0
Show compensated paths: +3
Graphic simulation without programmed tool axis: Tool radius (not TNC 410)
MP7315
0 to 99 999.9999 [mm]
Graphic simulation without programmed tool axis: Penetration depth (not TNC 410)
MP7316
0 to 99 999.9999 [mm]
Graphic simulation without programmed tool axis: M function for start (not TNC 410)
MP7317.0
0 to 88 (0: Function inactive)
Graphic simulation without programmed tool axis: M function for end (not TNC 410)
MP7317.1
0 to 88 (0: Function inactive)
Set the screen saver (not TNC 410)
Enter the time after which the TNC should start
the screen saver
MP7392
0 to 99 [min] (0: Function inactive)
