550 13 Tables and Overviews
13.5 A
ddr
esses (ISO)
Assigned addresses
Address Function
% Program start or program call
# Datum number with Cycle G53
A
B
C Rotation about X axis
Rotation about Y axis
Rotation about Z axis
D Definition of parameters (program parameters Q)
DL
DR Length wear compensation with tool call
Radius wear compensation with tool call
E Tolerance for M112 and M124
F
F
F
F Feed rate
Dwell time with G04
Scaling factor with G72
Factor for feed-rate reduction with M103
G Preparatory function, cycle definition
H
H
H Polar coordinates angle in incremental value/absolute value
Rotation angle with G73
Tolerance angle for M112
I
J
K Z coordinate of the circle center/pole
Y coordinate of the circle center/pole
Z coordinate of the circle center/pole
L
L
L Setting a label number with G98
Jump to a label number
Tool length with G99
LA Number of blocks for block scan with M120
M Miscellaneous functions
N Block number
P
P Cycle parameters in machining cycles
Parameters in parameter definitions
Q Program parameters/Cycle parameters
R
R
R
R
R Polar coordinate radius
Circular radius with G02/G03/G05
Rounding radius with G25/G26/G27
Chamfer section with G24
Tool radius with G99
S
S Spindle speed
Oriented spindle stop with G36
