Yaskawa GPD506/P5 to P7 - Manual (Page 14)

Product Transition Guide
GPD506/P5 to P7
Page 14 of 48
GPD506/P5 Terminal
P7 Terminal
(Designations similar to GPD506/P5)
Type
GPD506/P5
Terminal
Default Function & Description P7
Terminal
Default Function P7 Description
FS
+15V Power supply output for
analog command
(Allowable current, 20mA max.)
+V +15Vdc power output
+15Vdc
(Max. current: 20mA)
FV
Frequency reference input
(voltage) 0 to +10V/100%,
n043 = “FV=MSTR”:
FV enabled
n043 = “FI=MSTR”:
FI enabled
0 to +10V (20kW)
A1
Analog input or speed
command 0 to +10Vdc=100%
(20k ohm)
FI
Frequency reference input
(current) 4 to 20mA/100%
n043 = “FV=MSTR”:
FV enabled
n043 = “FI=MSTR”:
FI enabled
4 to 20mA (250W)
A2
Analog input or speed
command
4 to 20mA=100%/(250 ohms)
0 to +10Vdc=100%/(20k ohm)
Function set by H3-09.
FC
Common terminal 0V
AC Analog common –
Anal
og Input
Si
gnal
s
E(G)
Connection to shield sheath of
signal lead
E(G)
Shield wire, optional ground
line connection point
–
M1 M1
M2
During running (N.O. contact)
Closed when running.
Multi-function contact output
(n042)
Dry contact capacity:
250VAC 1A or less
30VDC 1A or less
M2
During run
(N.O. contact)
Form A Dry contacts capacity:
1 A max. at 250Vac
1 A max. at 30Vdc
Multi-function digital output.
Function set by H2-01.
–
–
M3
–
–
M4
Remote/Auto Operation
(N.O. contact)
Form A Dry contacts capacity:
1 A max. at 250Vac
1 A max. at 30Vdc
Multi-function digital output.
Function set by H2-02.
MA MA
MB MB
Dig
ital Ou
tp
u
t Sig
n
als
MC
Fault contact output
(N.O./N.C. contact)
Fault when closed between
terminals MA and MC
Fault when open between
terminals MB and MC
Multi-function contact output
(n041)
Dry contact capacity:
250VAC 1A or less
30VDC 1A or less
MC
Same function as
GPD506/P5. Non-
programmable
Form C Dry contacts
capacity:
1 A max. at 250Vac
1 A max. at 30Vdc
Anal
og Out
put
Si
g
nal
s
AM
Frequency meter output
0 to +10V/100% frequency
Multi-function analog monitor 1
(n052)
0 to +10V
2mA or less
FM Output frequency
0 to +10Vdc
10V=100% Output frequency
(Max current 2mA).
Function set by H4-01.
