Appendix 3- Parameter Cross Reference
Page 33 of 48
GPD506/P5 Parameter P7 Parameter
Param
No.
Nxxx
Parameter
Name
Description or Selection Description or Selection
Parameter
Name
Param.
No.
035 Cooling fin overheat
Stop method
selection 0: Deceleration stop
(Decelerate by deceleration time 1)
1: Coast to stop
2: Deceleration stop
(Decelerate by deceleration time 2)
3: Operation continues
(The alarm is displayed, and drive runs at
80% of the freq ref) Drive Operation upon OH Pre Alarm
Detection.
0: Ramp to Stop (Decel Time C1-02).
1: Coast to Stop
2: Fast-Stop (Decel Time = C1-09).
3: Alarm Only
*0 to 2 is recognized as fault detection, and
3 is
recognized as alarm. (For the fault
detection, the fault
contact operates.)
4: OH Alarm & Reduce (Continue
operation and reduce
output frequency by L8-19) Overheat Pre-Alarm
Operation Selection
L8-03
036 Multi-function
contact input 1
(terminal S2) 0: REV command (2wire sequence selection)
1: FWD/REV Command
(3wire sequence selection)
2: External fault. (N.O contact input)
3: External fault. (N.C contact input)
4: Fault reset
5: LOCAL/REMOTE switch
(run and freq ref)
6: Communication/Control circuit terminal
switch (run and freq ref)
7: Emergency stop (N.O. contact input)
8: Emergency stop (N.C contact input)
9: FV/FI terminal switch
10: Multistep speed set 1
11: Multistep speed set 2
12: Multistep speed set 3
13: Jog frequency select
14: Accel/decel time switch
15: External base block instruction
(N.O.contact input)
16: External base block instruction
(N.C contact input)
17: Speed search command from Max
frequency
18: Speed search command from set
frequency
19: Parameter set enable/disable
20: PID integral value reset
21: PID control disable
22: Timer start command
23: Inverter overheat
(blinking display of OH3)
24: Sample/holding of analog reference
25: KEB instruction (N.O. contact)
26: KEB instruction (N.C. contact)
27: Decel/accel prohibit
28: PID input characteristic switchover  Terminal S2 is not
programmable in P7 :
P7 default setting for terminal
S2:
Reverse run when closed,
stopped when open.
Initialization parameter
A1-03 programs terminals
S1 and S2 for 2-Wire or
3-Wire run control.
-
037
Multi-function
contact input 2
(terminal S3)
Set range: 2-28
(It is the same as constant n036)
0 to 70
Selects the function of terminal S3.
0: 3-wire control
FWD/REV selection for 3-wire sequence
1: Local/Remote Sel
Hand/Auto Selection - Closed = Hand,
Open = Auto
2: Option/Inv Sel
Selects source of speed command and
sequence
Closed = Option Card, Open = b1-01 & b1-
02
3: Multi-Step Ref 1
Closed = speed command from d1-02 or
Terminal A2,
Open = speed command determined by b1-
01
4: Multi-Step Ref 2
Closed = speed command from d1-03 or
d1-04
Open speed command determined by b1-01
Multi-Function Digital Input
Terminal S3 Function
Selection
H1-01
