Product Transition Guide
Appendix 1 –Ratings and Heat Loss Comparison
Page 23 of 48
Heat Loss Data
Note: Ampacity ratings vary between GPD506/P5 and P7 models.
Refer to NEC Ratings tables in Appendix 1 for the appropriate GPD506/P5 to P7 cross-reference.
GPD506/P5 (W) P7 (W) GPD506/
P5 Model
Internal Heatsink Total
P7
Model Internal Heatsink Total
23P7 80 135 215 23P7 74 110 184
25P5 90 210 300 25P5 84 164 248
27P5 110 235 345 27P5 113 219 332
2011 160 425 585 2011 168 357 525
2015 200 525 725 2015 182 416 598
2018 230 655 885 2018 208 472 680
2022 280 830 1110 2022 252 583 835
2030 500 1050 1550 2030 333 883 1216
2037 700 1250 1950 2037 421 1010 1431
2045 750 1550 2300 2045 499 1228 1727
2055 1000 1950 2950 2055 619 1588 2207
2075 1300 2300 3600 2075 844 1956 2800
2090 - 2090 964 2194 3158
2110 - 2110 1234 2733 3967
40P4 50 10 60 40P4 39 14 53
40P7 65 20 85 40P7 41 17 58
43P7 65 80 145 43P7 68 80 148
44P0 80 120 200 44P0 70 90 160
45P5 85 135 220 45P5 81 127 208
47P5 120 240 360 47P5 114 193 307
4011 150 305 455 4011 158 232 390
4015 180 390 570 4015 169 296 465
4018 195 465 660 4018 201 389 590
4022 260 620 880 4022 233 420 653
4030 315 705 1020 4030 297 691 988
4037 370 875 1245 4037 332 801 1133
4045 415 970 1385 4045 386 901 1287
4055 710 1110 1820 4055 478 1204 1682
4075 890 1430 2320 4075 562 1285 1847
4090 - 4090 673 1614 2287
4110 1160 1870 3030 4110 847 1889 2736
4132 - 4132 1005 2388 3393
4160 1520 2670 4190 4160 1144 2791 3935
4185 1510 3400 4910 4185 1328 2636 3964
4220 2110 4740 6850 4220 1712 3797 5509
4300 2910 6820 9730 4300 2482 5838 8320
