RIGOL
© 2007 RIGOL Technologies, Inc.
User’s Guide for DM3000 Series
5-6
Capacitance Characteristics
Accuracy Specifications (% of reading + % of range) [1]
Function Range [2 Test Current
1 Year
Tcal± 5℃
Temperature
Coefficient
0 ℃ to (Tcal–5 ℃) (Tcal+ 5 ℃) to
55 ℃
Capacitance
2.000nF 200nA 2 + 2.5 0.05+0.05
20.00nF 1uA 1 + 0.5 0.05+0.01
200.0nF 10uA 1 + 0.5 0.01+0.01
2.000uF 100uA 1 + 0.5 0.01+0.01
20.00uF 1mA 1 + 0.5 0.01+0.01
[1] Specifications are for 60 minute warm–up using Math Null. Additional errors may occur for non–film
capacitors.
[2] Specifications are for 1% to 120% of range on the 1nF range and 10% to 120% of range on all other
ranges.
