RIGOL
© 2007 RIGOL Technologies, Inc.
User’s Guide for DM3000 Series
5-16
Capacitance Characteristics
Accuracy Specifications (% of reading + % of range) [1]
Function Range [2] Test Current
1 Year
23℃± 5℃
Temperature
Coefficient
0 ℃ to 18 ℃
28 ℃ to 55 ℃
Capacitance
4.000nF 1uA 2 + 2.5 0.05+0.05
40.00nF 10uA 1 + 0.5 0.05+0.01
400.0nF 10uA 1 + 0.5 0.01+0.01
4.000uF 1mA 1 + 0.5 0.01+0.01
40.00uF 1mA 1 + 0.5 0.01+0.01
200.0uF 1mA 1 + 0.5 0.01+0.01
[1] Specifications are for 60 minute warm–up using Math Null. Additional errors may occur for non–film
capacitors.
[2] Specifications are for 1% to 120% of range on the 4nF range and 10% to 120% of range on all other
ranges.
