OPERATION GUIDE

1-1

1 Machine Parts

Main Body

1

Scan Unit

5

Toner Container

2

Front Cover

6

Developer Unit

3

Cassette

7

Drum Unit

4

Manual Feed Tray

5

2

1

3

4

6

7

9

8

10

11

12

13
14

8

Shipping Lock

12

Platen

9

Original Size Indicator Plate

13

Output Tray

10

Operation Panel

14

Paper Stopper

11

Original Cover
