User’s Manual of WGSD-10020 Series
476
Example:
Enable port queue shaper for all port & queue
WGSD-10020HP:/>qos Port QueueShaper Mode 1-10 0-7 enable
QoS Port QueueShaper Rate
Description:
Set or show the port queue shaper rate.
Syntax:
QoS Port QueueShaper Rate [<port_list>] [<queue_list>] [<bit_rate>]
Parameters:
<port_list> : Port list or 'all', default: All ports
<queue_list>: Queue list or 'all', default: All queues (0-7)
<bit_rate> : Rate in kilo bits per second (100-3300000)
Default Setting:
500kbps
Example:
Set the port queue shaper rate in 1000
WGSD-10020HP:/>qos Port QueueShaper rate 1-10 0-7 1000
QoS Port QueueShaper Excess
Description:
Set or show the port queue excess bandwidth mode.
Syntax:
QoS Port QueueShaper Excess [<port_list>] [<queue_list>] [enable|disable]
Parameters:
<port_list> : Port list or 'all', default: All ports
<queue_list>: Queue list or 'all', default: All queues (0-7)
enable : Enable use of excess bandwidth
disable : Disable use of excess bandwidth
