User’s Manual of WGSD / WGSW Layer 2+ Series
4.16.6 PoE Status
This page allows the user to inspect the total power consumption, total power reserved and current status for all PoE ports. The
screen in Figure 4-16-5 appears.
Figure 4-16-5: PoE Status Screenshot
The page includes the following fields:
Object Description
 Sequential Power On Displays the current sequential power on mode.
 System Power Budget Displays the maximum PoE power budget.
 Operation mode Displays the current PoE operation mode.
 Current Budget Displays the current maximum PoE budget.
325
