4.3.2 IP Configuration
This section provides the IP Configuration of PoE Injector Hub as the screen in Figure 4-3-2 appears. Table 4-3-2 describes
the IP Configuration object of PoE Injector Hub.
Figure 4-3-2: IP Configuration Web Page Screen
Object Description
 DHCP Client Allows to disable or enable the DHCP Client function of PoE Injector Hub.
 IP Address Allows to input new IP Address of PoE Injector Hub.
 Subnet Mask Allows to input new Subnet Mask Address of PoE Injector Hub.
 Default Gateway Allows to input new Default Gateway Address of PoE Injector Hub.
 Description
Allows to input new system description of PoE Injector Hub. The maximum length
is 20 characters.
 Apply Press this button to take effect.
 Reset Press this button to reset IP Configuration to default mode.
Table 4-3-2: Descriptions of the IP Configuration Objects Screen
If PoE Injector Hub has not received IP address from DHCP server, then user still can connect to the IP
address before changing to DHCP client mode, or user can use Smart Discovery Utility to find out what IP
address set in the PoE Injector Hub is currently.
