Power over Ethernet Applications
For the places hard to find the power outlet, the PoE Injector Hub provides the easiest way to power your Ethernet devices
such as PLANET Internet cameras and outdoor wireless access point installed on the top of the building.
To control the power system of your networking devices, the Gigabit PoE Injector Hub can directly co-work with PoE IP
Phone to build VoIP telephony network in the office. Furthermore, the Gigabit PoE Injector Hub can be directly connected to
any third party 802.3at / 802.3af devices and PoE switches installed 100 meters away.
Figure 1: PoE Injector Hub Application
