User’s Manual of WNRT-627
-88-
5.11.2 Host
Choose menu “ Access Control → Host”, you can view and set a Host list in the screen as shown in
Figure 5-41 . The host list is necessary for the Access Control Rule.
Figure 5-41 Host Settings
The page includes the following fields:
Object Description
Host Description Here displays the description of the host and this description is unique.
Information Here displays the information about the host. It can be IP or MAC.
Modify To modify or delete an existing entry.
Table 5-32
To add a new entry, please follow the steps below.
Step 1. Click the Add New… button.
Step 2. In the Mode field, select IP Address or MAC Address.
If you select IP Address, the screen shown is Figure 5-42 .
1) In Host Description field, create a unique description for the host (e.g. Host_1).
2) In LAN IP Address field, enter the IP address.
If you select MAC Address, the screen shown is Figure 5-43 .
1) In Host Description field, create a unique description for the host (e.g. Host_1).
2) In MAC Address field, enter the MAC address.
Step 3. Click the Save button to complete the settings.
