Page 11
11
Part names
4.
PHONO terminals (RCA)
Connect phono-level (MM cartridge) output devices.
•
Do not input line-level signals to the terminals.
•
Remove the short-circuit pin plugs from the terminals when connecting devices.
When you aren’t using the terminals, attach the short-circuit pin plugs to cut out
external noises.
5.
LINE terminals (RCA)
Connect multi players or line-level output devices.
6.
MIC 1 terminal (XLR or 1/4”/6.35 mm, TRS), MIC 2 terminal (1/4”/6.35 mm, TRS)
7.
Kensington security slot
Connect a cable lock.
8.
AC IN
Connect to a power outlet with the supplied power cord.
9.
SEND terminals (1/4”/6.35 mm, TS)
Connect to input terminals on external effects units.
•
If you connect equipment to the [
L (MONO)
] terminal only, mono sound is output.
10.
REC OUT terminals (RCA)
Connect a device for recording.
11.
MASTER 2 terminals (RCA)
Connect to analog input terminals on a power amplifier, etc.
12.
MASTER 1 terminals (balanced XLR)
Connect to analog input terminals on a power amplifier, etc.
•
Use the terminals for balanced output only.
•
Do not connect a power cord from another product to the terminals.
13.
BOOTH terminals (1/4”/6.35 mm, TRS)
Connect a booth monitor.
•
Use the terminals for balanced output only.
•
If you connect equipment to the [
L (MONO)
] terminal only, mono sound is output.
WARNING
Keep the short-circuit pin plugs out of the reach of children and infants. If accidentally
swallowed, contact a doctor immediately.
