Settings
Utility settings
MIXER SETTINGS
*: Factory setting
Setting items
Description
BALANCE
1
Sets the output balance.
•
Setting values:
L128
to
0
* to
R127
•
You can adjust the balance using the X-PAD.
MASTER OUT
1
PEAK LIMITER
Sets whether to adjust the analog master output that
exceeds the set value with peak limiter.
•
Setting values:
OFF
,
21dB
*
,
18dB
,
15dB
,
12dB
ATT.
Sets the attenuation level for the sound output from the
[
MASTER 1
] and [
MASTER 2
] terminals.
•
Setting values:
-12dB
,
-9dB
,
-6dB
,
-3dB
,
0dB
*
MONO/STEREO
Sets the output method (mono/stereo) for the sound output
from the [
MASTER 1
] and [
MASTER 2
] terminals.
•
Setting values:
MONO
,
STEREO
*
DIGITAL MASTER OUT
1
REFERENCE LEVEL
Sets the output level for when the master level indicator
lights up at [
0
] dB.
•
Setting values:
-30dBFS
,
-27dBFS
,
-24dBFS
,
-21dBFS*
,
-18dBFS
,
-15dBFS
,
-12dBFS
,
-9dBFS
,
-6dBFS
•
Sound may be distorted even when the master level
indicator doesn’t show the maximum level.
SAMPLING RATE
Sets the sampling rate for the digital signal.
•
Setting values:
44.1kHz
,
48kHz
,
88.2kHz
,
96kHz
*
