43
Multi I/O
• Return method : Routes the effect sound to a channel separate from the one with the
original sound. You can then mix the original sound and the effect sound using the two
channels.
For details on connections, see Connecting to the MULTI I/O terminals (page 23).
DJM-A9
CH3
MULTI I/O
TRIM/EQ/
SOUND COLOR FX
CH2
(RETURN)
TRIM/EQ/
SOUND COLOR FX
Effects unit/mobile device
Input
Output
Channel fader
Master volume
Channel fader
