Wireless LAN (Wi-Fi)
2 Turn the knurled part and remove the antenna from the unit.
 Connecting the wireless antenna
1 Align the wireless antenna horizontally with the antenna
terminal and turn the knurled part to attach it to the unit.
• Turn the knurled part and tighten it firmly (if it’s tightened correctly, there will be an
approximately 3 mm gap from the base of the mounting part). Be careful not to
overtighten it.
2 Turn the wireless antenna and adjust its angle to enable a
strong reception.
F
F
Knurled part
F F
Knurled part
3 mm
F
Rear panel of the unit
