Specifications
21
Head unit (Pan-tilt section)
Ambient operating
conditions
Temperature: -15 to +40°C, Humidity: 90%RH or less (non-condensing)
Wind speed
resistance
0 to 25 m/s: Operate normally, 25 to 35 m/s: Operable, 35 to 60 m/s: Not destroyed
Power supply 10.5 to 15 V DC, 90 W
Power of two or three times the rating 90 W may be consumed during power-on, so select a power supply
with specifications that prevent a power failure.
Wiper Provided
MIC input Provided (Pedestal section)
Washer Control terminal provided (Pedestal section)
Pan-tilt head
operations
Operation angle Operation speed
Panning -170° to +170°±5° 0.5°/s to 25°/s
Tilting -50° to +30°±5° 0.3°/s to 20°/s
Shot operations Pan/tilt/zoom/focus
Stopping accuracy For both pan and tilt operations less than 7' when no external forces are applied, less than 6' when external
forces are applied
Dustproof and
waterproof
performance
IP55
Acoustic noise NC55 or less*
* NC55 or less when operating speed is 10°/s or less
Control cable RS-422 cable
Depending on the system configuration, other unit or cable may be required.
Receptacle DC, control (RS-422), SDI output, SYNC input, AUX
Video output BNC1 system, 12G-SDI, 6G-SDI, 3G-SDI, HD-SDI output, embedded audio
GENLOCK input BNC1 system (tri-value/BB)
Pan-tilt head
securing
Mounted with four M8 bolts
Dimensions Refer to the external view ( A 22).
Mass Approx. 17 kg (including the camera, excluding the optional units)
