External View
22
External View
30°
50°
185
430
48.6
Mounting bolts M8 x 1.25 L=35
TILT swing range
Center of
TILT rotation
245
136
90
Receptacle unit (1:1)
(Unit : mm)
188
198
150
110
356 34
165.5
170°
170°
PAN swi
ng range
620
Center of
PAN rotation
Optical axis
74.5
58
252
80 92
244
128
