Pinnacle Systems STTS - Manual (Page 14)

8
JUMPER SETTINGS (Din-Rail controller)
1= jumper install
Number of Mats:
JP2 JP1
0 0 1 mat
1 0 2 mats
0 1 3 mats
1 1 4 mats
JP3
1= Manual relay resetting
0= Automatic relay resetting
JP4
1= External relay checking enabled
0= Disabled
JP5
Not used at this time
JP6
Not used at this time
