Page 18 DeviceNet interface 9.17.026
3.3.9 Elementary data Types
This section describes the data type specification syntaxes, data type value ranges and operations that can be
performed on the defined data types.
Table 2‐18: SUBSET OF ELEMENTARY DATA TYPES
Keyword Description Minimum range Maximum range
BOOL Boolean 0 1
SINT Short Integer ‐128 127
INT Integer ‐32768 32767
USINT Unsigned Short Integer 0 255
UINT Unsigned Integer 0 65535
UDINT Unsigned Double Integer 0 2^32‐1
REAL Floating Point IEEE 754 single floating point
DATE Date only D#1972‐01‐01 D#2151‐06‐06 (65536 days)
BYTE Bit string – 8 bits
WORD Bit string – 16 bits
STRING Character string (1 byte per character) See IEC1131‐3
SHORT_STRING Character string (1 byte per character,
1 byte length indicator) See IEC1131‐3
