BRONKHORST
®
Page 37
DeviceNet interface
9.17.026
10 DOWNLOAD TO MASTER
When needed baud rate for the master can be changed at [Settings][Bus parameter].
See example:
When slave has been installed and all settings are done the configuration has to be downloaded to the master.
Point to actual master and select [online][download]. When this is ready, from that moment on there will be data‐
exchange between master and slave. The green LED on the instrument will stop blinking and will go on continuously
when data‐exchange is O.K.
Example:
