Operators manual – Digi-Star StockWeigh 600 User Manual
Page 13
Operators Manual
D3656-US
9
(
Com 1 Delay
Choose the number of seconds the printer will
delay before advancing to the next print line.
Select one of the following:
OFF No delay
1
1 Second
.10
1/10 second
2
2 Seconds
.25
1/4 second
3
3 Seconds
.50
1/2 second
4
4 Seconds
.75
3/4 second
5
5 seconds
!
(
Com 2 Delay Not Used.
Display Count
Indicator displays count in increments of 0.01,
0.02, 0.05, 0.1, 0.2, 0.5, 1, 2, 5, 10, 20, 50,
and 100.
If the count is set too small, the readings will
be unstable and the indicator will not be
accurate.
Auto-Range
If “ON” the scale increases display count size
for weights over 300 and again at 600 lbs/kgs.
If set to “OFF” display counts are set and do
not vary.
For example: 0 to 300 lbs (1 lb Increment),
300 to 600lbs. (2 lbs Increments), 600 and up
(5 lbs. Increments).
*
Display Unit
Select desired weight unit to be displayed.
When changing weight unit using the long
form, the calibration is adjusted so the scale
displays accurately in the new display unit.
Capacity
Enter MAXIMUM weight measurable on scale.
