StockWeigh 600
18
.
There are ten scoreboard methods available. Methods one thru six
sends numeric display data out the RS232 port periodically while the
other methods send a data stream as described below.
1. Transmit numeric display data once per second.
2. Transmit numeric display data two times per second.
3. Transmit numeric display data three times per second.
4. Transmit numeric display data at the A-D conversion rate.
5. Transmit numeric display data at the display rate.
6. Transmit numeric display data whenever there is a display weight
change.
7. Transmit status data string every second. Status data string
includes weight, rotation counter data, date and time.
8. Transmit status data every five seconds. Status data string
includes weight, rotation counter data, date and time.
9. Reserved.
10. Transmit EID data string every 2 seconds.
NOTES:
When using SCOREM = 1, 2, 3, 4, 5, 6 and 9 be sure to set
LSTORE = OFF, TAREAP = OFF and APRINT = OFF to
avoid corrupted data when transmitting scoreboard data
and printing scale data.
When using SCOREM = 7, 8 and 10, print data will not be
corrupted by scoreboard data.
With COM IN set to EZ2CMD the port configuration is: 9600
Baud, 1 start bit, 7 data bits, 1 even parity bit and 1 stop bit.
With COM IN set to EZCMD the port configuration is:1200
Baud, 1 start bit, 7 data bits, 1 even parity bit and 1 stop bit.
