32
5
. C
o
n
trol Knobs
5.4 ASSIGN
The ASSIGN button can be used to set the CONTROL KNOBS to send MIDI
Continuous Controller information to external MIDI devices, or to control the
MP6’s Amp Simulator function.
5.4.1 Amp Simulator parameter
If the Amp Simulator is turned on, pressing the ASSIGN button allows the Amp
Simulator parameters to be adjusted using the CONTROL KNOBS.
Drv Lvl Lo Hi
0 127 0 0
Note:
The Amp Simulator is effective for Zone 1 only.
* Please refer to page 38 of this owner’s manual for further information about
the Amp Simulator.
5.4.2 MIDI CC# (Control Change)
If the Amp Simulator is turned off, pressing the ASSIGN button allows MIDI
Continuous Controller information to be sent using the CONTROL KNOBS.
The MP6 can send any MIDI Continuous Controller information to any MIDI
Instrument or Device. This powerful feature allows for editing the sounds of an
external sound module in Real Time during performance, or for recording Real
Time performance edits to a MIDI sequencer.
Some control changes are also effective to internal sounds.
Make sure that the ASSIGN button in the CONTROL KNOBS section is lit. If the
ASSIGN button is turned off, press it to turn it ON.
The CONTROL KNOBS are now active and assigned to the MIDI CC parameters.
Use the CONTROL KNOBS to change the MIDI continuous controller information
assigned to each knob as described below.
Each parameter of the Control Change has an adjustable range from 0 to 127.
When the selected zone is set to INT or BOTH, the display shows the parameter
names.
1 PAN STN VbR3VbD
-
0 0 0 0
When the selected zone is set to EXT, the display shows the MIDI CC numbers.
3 010 070 076 077
6
-
4 64 64 64
