89
1
3
. MIDI Implem
en
ta
tion
13.1 Recognized Data
13.1.1 Channel Voice message
Note off
Status 2nd Byte 3rd Byte
8nH kkH vvH
9nH kkH 00H
n = MIDI channel number : 0H - fH (ch.1 ~ ch.16)
kk = Note Number : 00H - 7fH (0 ~ 127)
vv = Velocity : 00H - 7fH (0 ~ 127)
Note on
Status 2nd Byte 3rd Byte
9nH kkH vvH
n = MIDI channel number : 0H - fH (ch.1 ~ ch.16)
kk = Note Number : 00H - 7fH (0 ~ 127)
vv = Velocity : 00H - 7fH(0 ~ 127)
Control Change
Bank Select (MSB)
Status 2nd Byte 3rd Byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number : 0H - fH(ch.1 ~ ch.16)
mm = Bank Number MSB : 00H - 7fH (0 ~ 127)
ll = BankNumber LSB : 00H - 7fH (0 ~ 127)
Modulation
Status 2nd Byte 3rd Byte
BnH 01H vvH
n = MIDI channel number : 0H - fH (ch.1 ~ ch.16)
vv = Modulation depth : 00H - 7fH (0 ~ 127) Default = 00H
Data Entry
Status 2nd Byte 3rd Byte
BnH 06H mmH
BnH 26H llH
n = MIDI channel number : 0H - fH (ch.1 ~ ch.16)
mm,ll = Value indicated in RPN/NRPN : 00H - 7fH (0 ~ 127)
*see RPN/NRPN chapter
Volume
Status 2nd Byte 3rd Byte
BnH 07H vvH
n = MIDI channel number : 0H - fH (ch.1 ~ ch.16)
vv = Volume : 00H - 7fH (0 ~ 127) Default = 7fH
Panpot
Status 2nd Byte 3rd Byte
BnH 0aH vvH
n = MIDI channel number : 0H-fH(ch.1 - ch.16)
vv = Panpot : 00H - 40H - 7fH(left ~center~right) Default = 40H(center)
