Kleenmaid Professional - Outdoor Cooking Centres 13
Assembling The Side Burner
1. Mount the inner cap and outer burner ring to the
burner.
See Fig 1.
2. Now fit the pot trivet in place. There are two
locating pins on the bottom of the trivet, these will
align with the holes on the top of the burner deck.
The pot trivet is keyed to ensure correct alignment.
See Fig 2.
3. The optional wok trivet (included in the pack) is
designed to accommodate most size wok pans. It
can be fitted to the top of the pot trivet. The wok
trivet is keyed to ensure correct alignment on the
pot trivet.
Note: The wok trivet should only be used when
cooking with a wok.
The wok trivet must be removed before closing the
lid of the side burner. Always allow the trivet to
cool before removal.
Side Burner Assembly Instructions
Fig. 1 Fig. 2
