44
208/240 V Plug
KilnMaster Wall Enclosure
Transformer
Pilot Relay
Electronic
Control Unit
50 Amp Contactor
Control Signal
Fuse
Wiring Diagram
KilnMaster
Controller
KM-1 Single Phase
Thermocouple
+
-
Red
Yellow
Inserted in
firing chamber.
208/240 V Receptacle
KilnMaster Wall Enclosure
Transformer
Pilot Relay
Electronic
Control Unit
40 Amp 3
φ
Contactor
Control Signal
Fuse
Wiring Diagram
KilnMaster
Controller
KM-1 Three Phase
Thermocouple
+
-
Red
Yellow
Inserted in
firing chamber.
208/240 V 3
φ
Plug
208/240 V 3
φ
Receptacle
3
φ
Pilot
Socket
