APPENDIX C
BASIC INSTRUCTIONS FOR CONNECTING EZ-TROL II TO A WIRELESS
NETWORK
The steps described below are the basic procedures on how you can connect EZ-Trol II to
a wireless network. Since there would be some differences on the brands and
specifications that you will use, please have your device reference manual on hand for the
correct configuration procedures.
Basic Requirements:
1. Wireless router
2. Internet connection (This is to keep softwares up to date.)
3. Wireless bridge device (This should be compatible with your wireless router.)
4. Network cable (This is to connect the wireless bridge to the EZ-Trol II Control Box.)
Steps:
1. Configure your wireless router to connect to the internet. This is brand specific, please
refer to your device manual on how to connect to the internet.
2. Configure the wireless settings and security settings on your wireless router. Refer to
your device manual for details.
3. Configure the wireless bridge to connect to your wireless router. Refer to your device’s
manual for the correct procedures.
4. Connect the wireless bridge to your EZ-Trol II controller.
