23 Xerox Duplicator
Master disc images that were loaded using a drive on the duplicator have
a .VEF extension. Master disc images that were loaded directly to the du-
plicator’s hard drive from a PC have a .ISO extension.
Loading a CD-ROM/DVD Master onto the Hard Drive
When you turn on your duplicator, after it has booted up, you should see
the following signifying your duplicator is ready.
NOTE: In this tutorial, the term partition(s) is also used to
refer to image files in the hard drive.
Step 1: Make sure the master Reading Source is set to Hard Drive.
It is very important to make sure the master Reading Source is set to the
hard drive in order to avoid unnecessary error messages. To check the mas-
ter Reading Source, use the up or down arrow button to navigate to the fol-
lowing screen.
Step 2: Press >> to enter the Select Source menu and you should see the
following screen.
Make sure it is located at the hard drive. If not, you need to press the up or
down navigation button to search for it.
Step 3: Press >> to submit your selection. After your selection has been
submitted, you should see the following screen.
Step 4: Load your master disc onto the hard drive. Use the up or down
arrow button to navigate to the following screen.
XEROX 2.14
1.Copy
XEROX 2.14
8.Select Source
Hard Drive Port 0.0
HITACHI HDS721616PL
XEROX 2.14
8.Select Source
