31 Xerox Duplicator
To enter the number, you need to use the up or down button to select the
number for each digit and use the >> or << button to move the cursor po-
sition right or left. Once you have finished, move the cursor to OK and press
>>. For example, if you want to specify a counter value of 21 (twenty one),
the 4-digit value would be 0021. To input the desired quantity, do the fol-
lowing, making sure the cursor is located at the first position.
Press the down button repeatedly until 0 is displayed.
Press the >> button once to move the cursor to the next position.
Press the down button repeatedly until 0 is displayed.
Press the >> button once to move the cursor to the next position.
Press the down button repeatedly until 2 is displayed.
Press the >> button once to move the cursor to the next position.
Press the down button repeatedly until 1 is displayed.
Now, we have 0021 displayed. Press the >> once and the cursor is now
moved to OK.
Step 7: Press the >> once to submit your counter value. You should now
see the following screen.
Note: If the above screen is displayed for more than two min-
utes, check your blank discs for quality.
Step 8: Allow 5 to 10 seconds for the duplicator to detect your hard
drive partition and blank discs as well. After your hard drive partition and
blank discs have been recognized, then you should see the following
screen.
Specify Counter:
[ X ] OK?
Preparing
Waiting for Blanks
