52
Operation
Operation of the CopperHead 3430AP Transceiver System
A Quick push of the BASE Rx/DIM Selector advances to the TEMP mode
TEMP Sequence starts with TEMP to indicate the display mode is temperature
MAIN The main Camera Unit controller board temperature will be displayed
TEMP Repeats that the display is in the TEMP mode
36C Temperature display in Centigrade for Camera Unit main circuit board
DIAGNOSTIC MODE Fan (FAN)
FAN When FAN appears and the Select button is held the cooling pan will cycle
through the MAX, NORMAL and QUIET modes. This function duplicates the Fan
Control on the Indicator side of the Camera Unit.
DIAGNOSTIC MODE Power (POWR)
A Quick push of the BASE Rx/DIM Selector advances to the POWR mode
LBUS Indicates that the LBUS controller board is being measured
POWR Indicates the display is in the POWER sub-mode
OK Indicates that the item is in an OK State
UBUS Indicates that the UBUS controller board is being measured
POWR Indicates the display is in the POWER sub-mode
OK Indicates that the item is in an OK State
OBOX Indicates that the Audio Interface Box controller board is being measured
POWR Indicates the display is in the POWER sub-mode
OK Indicates that the item is in an OK State
MAIN Indicates that the main camera unit controller board is being measured
POWR Indicates the display is in the POWER sub-mode
OK Indicates that the item is in an OK State
DIAGNOSTIC MODE Microcontroller Board Revision Version (REV)
A Quick push of the BASE Rx/DIM Selector advances to the REV mode. This mode displays
the microcontroller firmware revision of every board in the Camera Unit that has a micro-
controller.
(Note: the REV versions noted here were current as of December 1, 2013. Your system
may have different REV versions)
REV Indicates that the mode is REV
OBOX Indicates the OBOX microcontroller board is revision is being queried
REVY Indicates that the REV for the Audio Interface Box board is REVY
REV Indicates that the mode is REV
MAIN Indicates the MAIN microcontroller board is revision is being queried
REVI Indicates that the REV for the BASE Camera Unit controller board is REVI
REV Indicates that the mode is REV
UBUS Indicates the UBUS microcontroller board is revision is being queried
REVH Indicates that the REV for the UBUS board is REVH
Readout Camera Unoit Digital Display Activity Explanation
