Profile LVS Event Management System Instruction Manual
xxiii
Summary of New Features in Version 3.1
The features listed below are those developed in the LVS software version 3.1
from version 2.2E .
New Features
H Compatible with other Profile applications
Reading and writing standard Profile PDR Movies is now supported. Scenes
and highlights can be dragged and dropped into a PDR Movie tab in the
Library Window. This action will create a standard PDR Movie. PDR Movie
clips and masters can then be used by other Profile applications, and LVS
can use clips and movies created in other Profile Applications. The PDR
Movie tab also displays all the clip properties, similar to those displayed by
other Profile applications such as Media Manager.
When you create a PDR Movie, you can use the Protected Copy Movie
feature to ensure that any operations that you perform on the PDR Movie do
not interfere with LVS operation.
You can use Media Manager to perform Fibre Channel transfers of PDR
Movies, and store the material on digital data tapes with the PLS 20 desktop
tape drive. This feature is only available in the Enhanced Feature set.
H Gang Roll Playback
This feature allows one clip to be locked in sync with another. By interlock-
ing two events together, you can synchronise their cue–up and playback
Once you specify a master and slave clip, the slave is cued along with the
master. The two clips are locked together.
With a single action, both master and slave roll frame–accurately together.
This feature can be used to support Video Key 2–channel synchronous
outputs. This feature is only available in the Enhanced Feature set.
H Voice-Over in the Timeline Editor
A voice–over feature has been added in the Timeline window. This allows
you to arbitrarily insert–edit audio on any of the four audio tracks indepen-
dent of the video track. This feature is only available in the Enhanced
Feature set.
H Play list Window Upgrades
The following features are only available in the Enhanced Feature set.
D ON AIR button
