Specifications
Profile LVS Event Management System Instruction Manual
C-3
Live Controller
Table C-3: Live ControllerĂ
Item
Description
RSĆ422 Connectors
DSUB 9 pins 2
For the connector pin assignment and communication protocol, refer to the Profile
Installation Manual.
Power Source
Electrical Rating
Range
90 VAC to 250 VAC, 47 Hz to 66 Hz
Nominal
100 VAC to 240 VAC, 50 Hz/60 Hz
Supply Type
Single Phase
Supply Connection
Detachable cord set
Heat Dissipation
Power Consumption
v 14 W (0.5 A
rms
maximum line current at 50 Hz)
Dissipation
90 V line with 5 % clipping
AC Current
v 0.5 A
Surge Current
60 A (25°C) peak for v 5 line cycles,
after instrument has been turned off for at least 30 seconds.
Fuse
UL198G: 250 V, 2A, FAST (5 mm 20 mm)
for Canada only.
IEC127: 250 V, 2 A (T) (5 mm 20 mm)
for U.S. and Internaltional, except Canada.
Environmental Characteristics
Temperature
Operating
10°C to +40°C
Non-operating
-20°C to +60°C
Relative Humidity
Operating
20 % to 80 % (No condensation), Maximum wet-bulb temperature 29.4°C
Non-operating
5 % to 90 % (No condensation), Maximum wet-bulb temperature 40.0°C
Altitude
Operating
Up to 4.5 km (15,000 ft)
Maximum operating temperature decreases 1°C each 300 m
above 1.5 km (5,000 ft)
Non-operating
Up to 15 km (50,000 ft)
Vibration
Operating
0.7 g
rms
, from 5 to 500 Hz, 10 minutes
Non-operation
2.28 g
rms
, from 5 to 500 Hz, 10 minutes
