Chapter 3
INSTALLATION AND USE MANUAL
page
13
Technical features and technical specifications
Technical service – MCZ S.p.A. all rights reserved - Reproduction prohibited
3.2. CLIMASYSTEM
Climasystem F60
Technical specifications
Fuel type
Wood - Chips
Hourly consumption
2.4 kg/h – 1.6 kg/h
Maximum thermal power
kW 6.5 Kcal 5590
Minimum thermal power
-
Efficiency 63%
Heatable volume *
140/40-160/35–186/30
Minimum draught
12 Pa / 0.12 mbar
Smoke temperature
330°C
Smoke outlet
Ø 16 cm
Firebox dimensions
495x365
Net weight
100 Kg
External combustion air outlet
cm² 150
CO2 emission in smoke (13 %O2)
0,20%
Mass throughput of smoke
11.2 g/s
Chimney flue
Up to 5 mt
20x30 cm Ø22
Between 5 and 7 mt.
20x20 cm Ø20
Over 7 mt
18x18 cm Ø18
Note
The insert is an intermittent combustion device
* Data may vary according to the fuel used
Climasystem 60 RH-LH
Technical specifications
Fuel type
Wood - Chips
Hourly consumption
2.4 kg/h – 1.6 kg/h
Maximum thermal power
kW 6.5 Kcal 5590
Minimum thermal power
-
Efficiency 63%
Heatable volume *
140/40-160/35-186/30
Minimum draught
12 Pa / 0.12 mbar
Smoke temperature
330°C
Smoke outlet
Ø 16 cm
Firebox dimensions
495x365
Net weight
100 Kg
External combustion air outlet
cm² 150
CO2 emission in smoke (13 %O2)
0,20%
Mass throughput of smoke
11.2 g/s
Chimney flue
Up to 5 mt
20x30 cm Ø22
Between 5 and 7 mt.
20x20 cm Ø20
Over 7 mt
18x18 cm Ø18
Note
The insert is an intermittent combustion device
* Data may vary according to the fuel used
