Chapter 4
INSTALLATION AND USE MANUAL
page
17
Installation and assembly
Technical service – MCZ S.p.A. all rights reserved - Reproduction prohibited
4. Installation and assembly
IMPORTANT!
The insert must be installed and connected to the
chimney flue by specialised technicians or skilled
personnel so that every local or national regulation is
met and, in any case, in accordance with the
standard UNI 10683 REV.
When the insert is unpacked, make sure all parts are in perfect
working order and check for damages due to transport. If the
insert is being installed in a place with difficult access, it is possible to
lighten the weight by removing the internal components which make up
the firebox. Remember to correctly reassemble all elements.
Any disassembly and assembly of internal parts
must, however, be carried out by skilled and
authorised personnel.
MCZ will not be held liable for any breakage in the
event the aforesaid warning is not observed.
4.1. PREPARATION AND UNPACKING
Open the packaging, take off the bands, remove the insert from the
pallet and position it in the chosen location, taking care that its position
fully complies with the instructions.
The insert must always be kept in a vertical position during handling,
using the appropriate handles located on the sides. Be careful that the
door and its glass are protected from impacts that could jeopardise
their integrity. In any case, the product must always be handled with
care. If possible, unpack the insert in the area where it is to be
installed.
The materials which make up the packaging are not toxic or harmful,
so no special disposal procedures are required.
The end user must store, dispose of or recycle packaging material in
accordance with current regulations.
4.2. MAKING THE ELECTRICAL CONNECTIONS
Before positioning the insert, a 230V - 50 Hz electrical power outlet
must be prepared near the insert in order to connect the electrical cable
that powers the fans.
The power outlet must be equipped with an earth connection.
The wiring must be carried out by first cutting off the
electricity supply in the home.
When preparing the connection of the electrical cable
provided with the insert, be very careful not to crush
the cable while inserting the product. This could
cause short circuits that can damage the entire
electrical system.
Packaging example
