570
4-3. Do-it-yourself maintenance
23 ECU-B1 7.5 A
Multiplex communication system,
Multiport fuel injection system/
sequential multiport fuel injection
system, auto anti-glare inside rear
view mirror, power outlets, power
front driver’s seat, power tilt and
power telescopic
24 DOME 7.5 A
Interior lights, personal lights, van-
ity lights, engine switch light, foot
light, accessory meter
25 HEAD LH 15 A
Left-hand headlight
(high beam)
26 HEAD LL 15 A
Left-hand headlight
(low beam)
27 INJ 10 A
Multiport fuel injection system/
sequential multiport fuel injection
system, ignition system
28 MET 7.5 A Gauges and meters
29 IGN 10 A
SRS airbag system, multiport fuel
injection system/sequential multi-
port fuel injection system, cruise
control system
30 HEAD RH 15 A
Right-hand headlight
(high beam)
31 HEAD RL 15 A
Right-hand headlight
(low beam)
32 EFI NO.2 10 A
Multiport fuel injection system/
sequential multiport fuel injection
system, leak detection pump
33 DEF I/UP 5 A No circuit
34 SPARE 5 A Spare fuse
35 SPARE 15 A Spare fuse
36 SPARE 30 A Spare fuse
Fuse Ampere Circuit
