To check belt tension, place a straightedge (ruler)
across two adjacent pulleys and apply a force of 22 lbs
(98 N, 10 kg) midway between the pulleys by using a
spring scale. Belt deflection should be the amount
specified.
Manual transmission oil
Manual transmission oil
Oil level
Manual transmission
Checking the oil level
0
Non-turbo models
1) Yellow handle
Deflection
New belt
Used belt
A
0.28 – 0.35 (7.0 – 9.0)
0.35 – 0.43 (9.0 – 11.0)
B
0.30 – 0.33 (7.5 – 8.5)
0.35 – 0.40 (9.0 – 10.0)
1
UBB004DB
