The following notes apply to Table 3–1 and to the power cable definition:
1. The above figures are based upon insulated copper conductors at 25E C
(77E F), two current carrying conductors in the cable plus a safety (chassis)
ground.
Columns 3 and 4 refer to “one way” ohms and IR drop of current carrying
conductors (e.g., a 50-foot cable contains 100 feet of current carrying
conductor).
2. Determine which wire gauge for the application by knowing the expected peak
load current (I
peak
), the maximum tolerated voltage loss (V
loss
) within the cable,
and the one way cable length.
The formula below determines which ohms/100 feet entry is required from
Column 3. Read the corresponding wire gauge from Column 1.
(Column 3 value) =
V
loss
/[I
peak
x 0.02 x (cable length)]
Where:
Column 3 value =
Entry of the table above.
Cable length =
One way cable length in feet.
V
loss
=
Maximum loss, in volts, permitted within cable.
Special case: Should the V
loss
requirement be very loose, I
peak
may exceed the
maximum amperes (Column 2). In this case, the correct wire gauge is selected
directly from the first two columns of the table.
Example:
If the cable length was 10 feet, the Column 3 value would be 0.125 and the
corresponding wire gauge would be 10 AWG.
A 20 ampere (I
peak
) circuit which may have a maximum 0.5 volt
drop (V
loss
) along its 15-foot cable (one way cable length) requires (by formula)
a Column 3 resistance value of 0.083. This corresponds to wire gauge size 8
AWG.
3. Aluminum wire is not recommended due to soft metal migration at the terminals
which may cause long term (on the order of years) poor connections and
oxidation. If used, increase the wire gauge by two sizes (e.g., specify 10 gauge
aluminum instead of 14 gauge aluminum).
