Elgar CW-P Series Programming
Operation Manual 4-3
When the left MEASURE and the WATTS LEDs are illuminated, the wattage being
sourced at the output terminals is displayed on the left display.
Measured Wattage
When the left MEASURE and the OVP LEDs are illuminated, the over-voltage setpoint
is displayed on the left display.
Displaying Overvoltage Setpoint
When the left MEASURE and the VA LEDs are illuminated, the apparent power, in volt-
amps, being sourced at the output terminals is displayed on the left display.
Measured Volt-Amps
When the left MEASURE and the PF LEDs are illuminated, the power factor measured
at the output terminals is displayed on the left display.
Measured Power Factor
4.2.2 Supply Measurements on the Right Display
To change which item is displayed at measure time, press MEASURE repeatedly until
the desired LED is illuminated.
When the right MEASURE and the AMPS LEDs are illuminated, the RMS current
measured at the output terminals is displayed on the right display.
Measured Current
When the right MEASURE and the Hz LEDs are illuminated, the frequency measured at
the output terminals is displayed on the right display.
Measured Frequency
When the right MEASURE and the Pk AMPS LEDs are illuminated, the instantaneous
peak current is displayed on the right display.
Instantaneous Peak Current
When the right MEASURE and the CF LEDs are illuminated, the crest factor measured
at the output terminals is displayed on the right display.
Measured Crest Factor
Note: When the output current is less than 5% of the full rated current, the crest factor
is not applicable.
The SLAVECONFIG parameter only applies if the SLAVEADDR is set to 0
and the SLAVECHAN is set to A on the A master unit. Only the A phase master uses
this parameter.
