Installation Elgar CW-P Series
2-18 Operation Manual
Setup 1–Phase Master/Slave Pair Using Menu System
1. Ensure load wiring is removed from the two CW units.
2. Ensure no master/slave cables are attached to “Analog Slave” connectors on CW
units.
3. Ensure no master/slave cables are connected to the “M/S IN “ and “M/S OUT”
connectors.
4. Connect the mains wiring to the line terminals.
5. Power up both CW units.
6. On the master CW press the “ENTER/SAVE” button.
7. Rotate the left knob CW until the left display reads “ConF”.
8. Rotate the right knob until the right display reads A0A1.
9. Press the ENTER/SAVE button.
10. Press the ENTER/SAVE button.
11. Rotate the left knob CW until the left display reads “Addr”.
12. Rotate the right knob until the right display reads 0.
13. Press the ENTER/SAVE button.
14. Press the ENTER/SAVE button.
15. Rotate the left knob CW until the left display reads “ChAn”.
16. Rotate the right knob until the right display reads A.
17. Press the ENTER/SAVE button.
18. On the slave CW press the ENTER/SAVE button.
19. Rotate the left knob until the left display reads “Addr”.
20. Rotate the right knob until the right display reads “1”.
21. Press the ENTER/SAVE button.
22. Power down both CW power supplies.
23. Connect Elgar cable 890-497-40 between the master “Analog Slave” and the
slave “Analog Slave” connectors.
