Programming Elgar CW-P Series
4-4 Operation Manual
4.3 Menu Operations
There are two buttons in the Menu section of the front panel, ENTER/SAVE and
ESCAPE. Press the ENTER button to enter the Menu system. The MENU/STATUS
LED lights and the left and right displays are overridden to provide menu system
readouts. When in the Menu mode, the two MEASURE and two PROGRAM LEDs are
all turned off.
Use the Menu system to display and/or change the following parameters:
• Check the self-test result
• Set the GPIB port address
• Specify current Foldback/Shutdown
• Specify current shutdown delay
• Specify PROGRAM keys lock out
• Store system parameters
• Recall system parameters
• Specify whether the output relay will automatically close at power-up
• Specify Clock Signal as an Input or an Output
• Analog input
• RMS loop On/Off
• Phase A offset
• Phase B offset
• Phase C offset
• Slave channel
• Slave address
• Slave configuration
The menu is flat in its design and the various major nodes are available by rotating the
left knob either clockwise or counterclockwise to move either down or up on the list
given here.
