Elgar CW-P Series Installation
Operation Manual 2-21
Setup Six CW Units as 3–Phase Master/Slave Set using Menu System
1. Ensure load wiring is removed from the six CW units.
2. Ensure no master/slave cables are attached to “Analog Slave” connectors on
CW’s.
3. Ensure no master/slave cables are connected to the “M/S IN “ and “M/S OUT”
connectors.
4. Connect the mains wiring to the line terminals.
5. Assign labels to the six CW units “A master”, “B master”, “C master”, “A slave”, “B
slave”, “C slave”.
6. Power up six CW units.
7. Set up the A phase.
8. On the A master CW press the “ENTER/SAVE” button.
9. Rotate the left knob CW until the left display reads “ConF”.
10. Rotate the right knob until the right display reads A0C1.
11. Press the ENTER/SAVE button.
12. Press the ENTER/SAVE button.
13. Rotate the left knob until the left display reads “ChAn”.
14. Rotate the right knob until the right display reads “A”.
15. Press the ENTER/SAVE button.
16. Press the ENTER/SAVE button.
17. Rotate the left knob until the left display reads “Addr”.
18. Rotate the right knob until the right display reads “0”.
19. Press the ENTER/SAVE button.
20. On the A slave CW press the ENTER/SAVE button.
21. Rotate the left knob until the left display reads “Addr”.
22. Rotate the right knob until the right display reads “1”.
23. Press the ENTER/SAVE button.
24. Press the ENTER/SAVE button.
25. Rotate the left knob until the left display reads “ChAn”.
