Operation Manual 4-1
SECTION 4
PROGRAMMING
4.1 Programming the CW Via the Front Panel
Press the PROGRAM button in the VOLTAGE/POWER section to enter Program mode.
The PROGRAM LED lights up and the last programmed value appears in the digital
display. The associated LED lights to show which item (voltage or overvoltage) is being
programmed. The rotary knob will be active and any change made to the setpoint being
adjusted is final as it is made. Press any button to exit the Program mode.
Front panel button functions are as follows:
• If the PROGRAM button is pressed, the CW moves the program focus to the next
program item in line.
• If a MEASURE button is pressed, the CW reverts to the previous Measurement
mode without changing the measurement focus.
• If the V RANGE button is pressed while in Program Voltage mode, the CW performs
a range change operation and the VOLTAGE/POWER section remains in Program
Voltage mode.
• If the ENTER/SAVE button in the MENU/STATUS section is pressed, the menu
system appears on the display.
• If the ESCAPE or ENTER/SAVE button in the MENU/STATUS section is pressed
when in the menu system, menu operations are terminated and Measurement mode
is re-entered.
• If there is no front panel activity for 10 seconds while in Menu or Program modes,
the CW reverts to the Measure modes. The PROGRAM and programmed
parameter LEDs turn off, and both MEASURE LEDs are lit.
• By rotating the programming knobs slowly, the changing parameter steps up/down
in small steps. By increasing the rotation speed of the knob, an “acceleration”
algorithm will increase the size of the changed value granularity and the parameter
will increase/decrease faster.
