3.4.3

C hanging the toothed beltofthe ejector

C aution:R isk ofinjury!

S w itch the m ain sw itch off.

C hange the toothed beltonly w ith the sew ing unitsw itched off.

–

Low erthe feeding unitonto the table top m anually.

–

S w itch the sew ing unitoff.

–

S crew the screw 3 outofthe cylinder2.

–

Loosen screw 4 and release the tension ofthe toothed belt5.

–

R em ove the toothed beltfirstfrom the drive rolland then from the
feed roller6 ofthe ejector.

–

Fitthe new toothed beltin reverse order.

–

Tension toothed belt5 and tighten screw 4.
Ifthe tension is correct,itm ustbe possible to bend the toothed
belt5 in the m iddle by approx.10 m m w ith sensible counter
pressure.

–

S w ivelthe cylinder2 to the frontagain and screw iton the ejector
w ith screw 3.

35

3

3

2

1

6

5

4
